High-speed 3250 Solenoids for Microphone Dispensing

Dispensing volume Minimum 0.8 nl single dot

Minimum dot diameter 170 µm

Spray pressure 1-1000 bar (adjustable)

Frequency Up to 3000 Hz

Optional heating system Controllable nozzle heating: 180°C

Standard interfaces RS-232C; 24V/5 V PLC, AUX

Power supply access 110/230 V AC, 50/60 Hz Power connector (rear)

Fast top calibration configuration

High-speed piezoelectric technology

Accurate and reproducible jet dispensing results

Ultra-precise non-contact jet dispensing

Ultra-wide range of applications

The new generation of high-speed dispensing valves, the MDV3250+FC series, is equipped with a high-performance piezoelectric actuator

Ultra-high needle lift and force make it particularly suitable for dispensing high-viscosity fluids High-speed piezoelectric technology

High-speed piezo technology speeds up the dispensing cycle

Ultra-fast opening/closing of the valve

Fast tip calibration configuration

The latest tip calibration design reduces needle and nozzle calibration time

Cost savings

Cost savings due to freely available needles, nozzles, and new and used accessories

Modular valve body design separates wet and dry zones for fast and safe replacement of wet zone parts, resulting in maintenance savings

Easy and fast cleaning and replacement of accessories reduces downtime

Repeatable Jet Dispensing Results

The system delivers highly consistent dispensing of single dots (as small as 0.8 nanoliters) or beads

Error values (CV) as low as 1%.

Ultra-Precise Non-Contact Dispensing

Ultra-precise, non-contact fluid dispensing designed to meet a wide range of fluid viscosities (up to 2 million mPas)

Consistent lightweight design maximizes dispensing accuracy

Wide range of applications

Modular design makes the MDS3250+FC Series suitable for a wide range of user-defined applications

Customizable connecting wires designed to reduce space requirements

Valve Memory Expansion

The MDV3250+FC has four times the memory space compared to the MDV3200A

The MDC3290+ provides storage for a wide range of application-related information.

Fully Compatible

Fully compatible with all Micromis consumables and spare parts for maximum configuration flexibility

Also compatible with earlier XY axis dispensing systems

Selectable Pin/Program Mode

Selectable Pin and Program Mode allows spot size and speed to be changed at any time during the dispensing process.

Programmable Program Mode is available for virtually any application requirement.
